More Pictures of AT6 Texan Power Module System

 at0014u 300x201 drop shadow copy.jpg (20772 bytes)

Picture of fuselage with aft fixed firewall and retaining studs. Power Module consisting of forward removeable firewall and tank has been completely removed from fuselage



 at0014u_texan_powermodule_removed copy.JPG (17656 bytes)

Picture of Power Module during insertion process. The forward removeable firewall and tank assembly (right) are slid into the fuselage to mate with the fixed aft firewall (left).

 at0014u_texan_powermodule_halfinserted copy.JPG (16735 bytes)



Picture showing completely inserted and installed Power Module after retaining nuts applied to studs.



 at0014u_texan_powermodule_installed copy.JPG (15706 bytes)
